Frameless Light Panel

Frameless light panels use an optimized structural design to conceal or minimize the visible frame, creating a clean and integrated illuminated appearance. With a borderless visual effect, uniform illumination, and a refined installation finish, they are suitable for premium displays, commercial spaces, advertising lighting, and custom illuminated applications.

Send Inquiry

Product Information

Introduction

A frameless light panel is an LED surface-lighting assembly designed for visually refined applications. By optimizing the light guide structure, LED layout, and edge treatment, it minimizes the visual impact of conventional frames and creates a cleaner, more continuous illuminated surface.

Compared with traditional framed light panels, the frameless design provides a more integrated appearance and allows the illuminated surface to blend more naturally into the surrounding environment.

Size, thickness, mounting structure, LED configuration, and edge treatment can be customized according to different spatial and product design requirements.

Product Features

Features

Integrated Visual Design

Minimizes conventional frame elements to create a cleaner and more seamless illuminated appearance.

Concealed Edge Design

Optimized edge structures and mounting methods reduce visible borders and improve presentation.

Uniform & Stable Illumination

Optimized light guide structures and LED layouts provide soft, even surface lighting.

Flexible Structural Customization

Supports custom sizes, mounting methods, edge structures, and optical configurations.

Premium Applications

Suitable for display and commercial projects with high requirements for appearance and spatial integration.

Specifications

Technical Specifications.

Reference specifications for project evaluation, product selection and engineering review.

Specification	Details
Product Type	Frameless LED Light Panel Assembly
Lighting Method	Edge-Lit Surface Illumination
Light Guide Material	Optical-grade PMMA
Light Source	LED Strip
Lighting Effects	Standard White / RGB / Custom Dynamic Multicolor Effects
Color Temperature	Customizable from 2700K to 6500K
Brightness	Adjusted according to project requirements
Optical Efficiency	80%–98%, depending on structure and optical design
Size	Customizable
Thickness	Customizable
Edge Structure	Frameless Design / Concealed Structure
Installation	Recessed Installation / Custom Mounting Structure
Decorative Surface Materials	UV Printing / DuPont Paper / Resin / Natural Stone / Agate and Other Decorative Materials
Optical Materials	Optional Diffuser Plate, Reflective Film, etc.
Electrical Requirements	Matched according to project requirements
Driving Method	Customizable
Illumination	Single-Sided / Double-Sided

When selecting a frameless light panel, factors such as appearance requirements, installation space, illuminated area, brightness, and structural fixing method should be considered.

By combining the light panel with different decorative materials, integrated illuminated surfaces can provide both functional lighting and decorative effects for premium commercial spaces, art displays, architectural interiors, and custom lighting projects.

We can provide frameless structural optimization, optical matching, and installation design according to project requirements to achieve a consistent and integrated lighting effect.

When installing a frameless light panel, use a suitable fixing method based on the product structure and ensure that the LED light source, electrical connections, and heat dissipation conditions meet the application requirements.

Avoid squeezing, excessive pressure, or damage to the illuminated surface during installation to ensure stable long-term operation.

Installation

Avoid squeezing, excessive pressure, or damage to the illuminated surface during installation to ensure stable long-term operation.
