Flexible LED Sheet

A flexible LED sheet combines a flexible substrate with high-density LED light sources to provide stable and uniform illumination. Its slim, lightweight, and flexible construction allows easy integration into different structures. The sheet supports cutting in single-LED or two-LED sections, while multiple sheets can be connected to create large-area illumination. Flexible LED sheets are widely used in fabric light boxes, large display lighting, advertising signage, backlit stone applications, and custom illuminated projects.

Send Inquiry

Product Information

Introduction

A flexible LED sheet is a surface-lighting product that combines a flexible substrate with LED light sources. Through optimized LED layout and optical design, it provides continuous and uniform illumination across the lighting surface.

Compared with conventional rigid light sources, flexible LED sheets offer greater flexibility and adaptability to different installation structures. They can be bent, cut, or combined according to installation requirements, making them suitable for curved surfaces, irregular shapes, and space-constrained lighting applications.

Based on the predefined cutting circuits, the sheet can be cut in single-LED or two-LED sections for flexible adjustment to specific dimensions. Multiple LED sheets can also be connected to create larger illuminated areas and accommodate different structural requirements.

The lightweight construction makes transportation and installation easier, particularly for large-area lighting applications. Size, brightness, color temperature, LED layout, and connection methods can be customized according to project requirements.

Flexible LED sheets are suitable for fabric light boxes, backlit stone and marble applications, display lighting, advertising signage, and other large-scale or custom illuminated projects.

Product Features

Features

Flexible Structure

Uses a flexible substrate to improve installation adaptability, allowing the LED sheet to fit different spatial structures, curved surfaces, and complex installation environments.

Ultra-Thin & Lightweight Design

The slim and lightweight structure requires minimal installation space and is easier to transport and install than conventional light guide plate systems, making it suitable for space-constrained and large-area lighting applications.

Flexible Cutting & Modular Connection

Supports cutting in single-LED or two-LED sections along predefined cutting lines. Multiple LED sheets can also be connected to accommodate different dimensions and illuminated areas.

Uniform & Stable Illumination

Optimized LED layout and optical design provide soft, uniform, and stable surface illumination while reducing dark areas and visible hot spots.

Flexible Customization

Supports customization of size, brightness, color temperature, LED density, circuit layout, and connection methods according to different project requirements.

Versatile Applications

Suitable for LED light boxes, fabric light boxes, display cabinets, advertising signage, commercial displays, backlit marble and stone applications, and other custom illuminated projects.

Specifications

Technical Specifications.

Reference specifications for project evaluation, product selection and engineering review.

Specification	Details
Product Type	Flexible LED Sheet
Substrate	Flexible Printed Circuit (FPC)
Light Source	LED Chips
Illumination	Surface Illumination / Custom Lighting Configuration
Lighting Effects	Standard White / RGB / RGBW, customizable
Color Temperature	Customizable from 2700K to 6500K and other color temperatures
Brightness	Adjusted according to project requirements
LED Layout	Customized according to brightness and uniformity requirements
Cutting Options	Single-LED Cut / Two-LED Cut, depending on circuit layout
Modular Connection	Multiple LED sheets can be connected
Size	Customizable
Voltage	Matched according to project requirements
Control Method	PWM / Controller / Smart Control Options
Installation	Adhesive Mounting / Fixed Structure / Custom Installation

When selecting a flexible LED sheet, factors such as installation space, illuminated area, brightness requirements, cutting configuration, number of connected modules, and electrical parameters should be considered.

For lighting applications requiring flexible size adjustment, modular combinations, or greater structural adaptability, flexible LED sheets provide a versatile light source configuration.

We can provide custom LED layout design, dimensional matching, optical optimization, and volume production according to project requirements for different lighting applications.
